Main technical parameters ( geared )

Rated Capacity (kg)	Rated Speed (m/s)	Car Size		Door Size		Hoistway Dimenisons				Machine Room Dimensions
		AA(mm)	BB(mm)	JJ(mm)	HH(MM)	AH(mm)	BH(mm)	PH(mm)	OH(mm)	AM(mm)	BM(mm)	HM(mm)
630	0.5	1340	1250	1200	2200	2250	1800	≥1400	≥4500	3000	3200	≥2500
	1.0
1000	0.5	1340	1850	1200	2200	2250	2400	≥1400	≥4500	3000	3800	≥2500
	1.0
1600	0.5	1640	2250	1500	2200	2800	2800	≥1400	≥4500	3200	4200	≥2500
	1.0
2000	0.5	1940	2250	1500	2200	2900	2800	≥1400	≥4500	3200	4200	≥2500
	1.0
3000	0.25	2440	2350	1800	2400	3600	2900	≥1700	≥4900	4000	4500	≥2500
	0.5
4000	0.25	2440	3150	2200	2400	3800	3700	≥1700	≥4900	4500	4500	≥2500
	0.5
5000	0.25	2440	3850	2200	2400	3800	4400	≥1700	≥4900	4500	5000	≥2500
	0.5
